| Pickling Line | ||||||||||||||||||||||||
Push-pull Pickling LinePush-pull Pickling is a semi-continuous production line. It is characteristic with lower consumption,easier operation and fewer malfunctions,moreover it can pickle many kinds of incoming material.The line can produce 100,000-600,000 tons strip annually.
Process FlowPay off → Reel Nine-roll Leveller → End Shear → Riveter → Entry Looper → Pre-rinsing Section Pickling Tank → Rinsing Tank → Hot Air Drier → Exit Looper → Deflector → Disc Shear(with scrap coiler) → Bridle RolI → Shear → Oiler → CoilerProcess ParameterFollowing is the data for Push-pull Pickling hot rolled strip with the annual yield of 400,000 tons
Continuous PickIing LineContinuous Pickling is a production line that the steel strip is pulled continuously through the acid tank and rinsing tank.The line is characteristic with high efficiency and output,and low electric consumption.The annual yield of the line is 600,000-1,000,000 tons.Process FlowCoil Prepare Station→Coil Car→Pay-off Reel→Pinch Straightener→Cutting Shear→Welder→1#Bridle Roll→Entry Accummulator→Front Tension Reel→Descaler→Back Tension Reel→Pickling→Ice Water Clean→Hot Water Clean→Dryer→2#Bridle Roll→Exit Accummulator→Bridle Roll→Control Roll→Cutting Shear→Disc Shear→Feeder→4#Bridle Roll→Oiler→Pinch Roll→Tension Roll→Unloading CarProcess Parameter
| ||||||||||||||||||||||||
| prev ：Hydraulic Coiler next ：Degreasing & Rinsing Line | ||||||||||||||||||||||||
  |
