The acid continuous rolling mill was intelligently manufactured in Wuxi Wuye

Warmly congratulate the successful installation and commissioning of Wuxi Wuye company make 600mm acid continuous rolling mill.

888
Model:Φ205X600/Φ600X580mm 4-stand pickling and tandem mill.
1. Raw material
Material status Material Max coil weight OD of material ID of  material Thickness Width
hot rolled steel coil carbon steel 8.5T φ1700 φ508 2.5-4.0mm 330-520mm

2. Product
Max coil weight OD of material ID of  material Thickness Width
8.5T φ1700 φ508  0.7-3.0mm 330-520mm

3. main technical parameters
Max rolling force Rolling speed Rolling method
≤500T ≤420m/min(4th stand discharge speed ) hydraulic screw down
prev :The 850mm double-uncoiler & double-coiler tandem mill was intelligently manufactured in Wuxi Wuye company
